Stable operation, good wind resistance and burglarproof performance. Suitable for all kinds of factories, commercial buildings, and garages.
Specifications
- Max dimension: Wide 12m. high 10m
- Wind resistance: Beaufort scale 12 (35 m/s)
- Running speed: 5 – 12 m/min
- Power supply: 1-phase 220V ± 15%V or 3-phase 380V ± 15%V, 50/60Hz
- Thickness of slats: 0.8 mm, 1 mm, 1.2 mm, 1.4 mm
- Work life: 20 years
- Installation methods: Interior installing, exterior installing, middle installing
Model characteristics
- Excellent wind resistance: Slats made from 0.8 mm thick or above galvanized steel. It is formed with cold-processing and made into special arc section. The elevation structural strength is improved by 85%. It can resist Beaufort scale 12 wind, namely 35 m/s.
- Advanced driving system: In-built limit device controls running precisely; Overload-protection model will stop motor from running when there is jamming or overheating, to protect the motor.
- Anti-corrosive: Dual protection. Slats and guide rails are made from galvanized steel. And surface is treated with electrostatic powder spraying coating.
- Stable and quiet running: Roller is rectified by Laser-beam method, to guarantee straightness and coaxial rotation. When door running, the slats can move at same pace without deviation and blocking.
- Convenient operation methods: Every door is euipped with a set of control button box, for daily operation. Optional remote control is available as additional choice.
- Auto-Manual dual operation modes: When there is power failure or breakdown, the door can be opened or closed by manual operation chain.
- Beautiful: The surface is painted. All RAL colors can be chosen to harmonize with the overall style of building.
