Specifications
- Max dimension: Wide 6m, high 6m
- Wind resistance: Beaufort scale 11 (30 m/s)
- Running speed: 6 – 15 m/min
- Power supply: 1-phase 220V ± 10%V, 50/60 Hz
- Work life: 20 years
- Sound insulation: 20 dB
- Thermal insulation: R = 11.38
- Installation methods: Interior installing, exterior installing, middle installing
Model characteristics
- Good thermal and sound insulation: Double layer slats can prevent thermal conduction and noise
- Good seal: There is seal brush inside guide rail, and EPDM seal rubber at the bottom. Gaps at two sides and bottom are eliminated
- Saving installation space: Special design tubular motor is inbuilt into the roller. Integrated design saves space at the top.
Various types of slats available
- Standard type – Double layer hollow aluminum alloy
- Excellent thermal and sound insulation – Double layer PU sandwich panel
- High strength and good wind resistance, for very big doors
